Img yellow jacket 95760

Recover-Xlt Unit 115/60 – PRODUCT: 95760

SKU: 686800957609

$2,210.40
Estimated delivery date 2026/03/03

Description

The YELLOW JACKET® RecoverXLT® has all the features you need for fast and effective refrigerant recovery. The single control valve makes it easy to operate. The dual-gauge design allows for monitoring of the system and tank pressures simultaneously and the integrated low-pressure switch automatically powers down the machine when the system reaches 15” of vacuum. The 1.25 hp, twin cylinder, oil-less compressor backed by a 3-year warranty provides fast recovery of Class III, IV and V refrigerants including R-410A. Gravity-drain condenser and high efficiency fan keep the recovery cylinder cooler, even in hot weather. Integrated purge circuit clears residual refrigerant from the machine, preventing cross-contamination when changing from one refrigerant to another. The RecoverXLT® helps you get the job done right
  • Capabilities:  Vapor, liquid, push/pull Refrigerants: All Class III, IV, and V, including R-410a refrigerants Compressor: 1.25 hp, twin cylinder, oil-less Power Source: 100-240VAC, 50/60Hz Amps: 12.0A High-Pressure Shut-Off: 517 psi/35 bar – auto reset Operating Temperature: 40° to 122°F (0° to 50°C) Weight: 26.7 lbs (12.1 kg) Dimensions: 19.3”L x 12.5”W x 12.4”H (490mm x 317mm x 315mm) See Product Spec Sheet under documents for UL Certified Rates for ARI 740-2016 for R12, R-134a, R-22, R-410, R-500 and R-502. The RecoverXLT™ is approved for use with other refrigerants which have not been certified for a particular recovery rate including, but not limited to: R1234YF, R-22, R-32, R134A, R-401A, R401B, R-402A, R-402B, R-404A, R-406A, R-407A, R-407B, R-407C, R-407D, R-408A, R-409A, R-410A, R-411A and R-411B, R-454B, R-500, R502.
    • A2L Compatible
    • Single valve control for easy changeover from liquid to vapor to purge
    • Robust compressor design for fast recovery of liquid and vapor refrigerant
    • Advanced 1.25 hp, twin cylinder, oil-less compressor with precision valves
    • Recovers refrigerant and shuts off when unit reaches 10″ of vacuum
    • Status indicator LED provides notification of machine faults and completed recovery
    • Quiet running with components nested to reduce vibration and noise – oil-less compressor is inherently quiet
    • Controls and gauges inset for protection and angled for easy access and viewing
    • Senses back pressure from tank and shuts off automatically at 517 psi for safety
    • Reusable mesh particulate filter inserts into suction port for protection – simple cleaning eliminates replacement due to clogging
    • ”On-the-fly” purge with simple turn of a knob to remove residual refrigerant and help prevent cross-contamination
    • High efficiency fan keeps air moving across condenser for cool running even in hot weather
    • High strength HDPE case for lightweight and rugged use –rounded corners help protect from nicks and scrapes

Specifications

Capabilities

  Vapor, liquid, push/pull

Refrigerants

All Class III, IV, and V, including R-410a refrigerants

Compressor

1.25 hp, twin cylinder, oil-less

Power Source

100-240VAC, 50/60Hz

Amps

12.0A

High

Pressure Shut-Off: 517 psi/35 bar – auto reset

Operating Temperature

40° to 122°F (0° to 50°C)

Weight

26.7 lbs (12.1 kg)

Dimensions

19.3”L x 12.5”W x 12.4”H (490mm x 317mm x 315mm)

Advanced 1.25 hp, twin cylinder, oil

less compressor with precision valves
